The Raijintek Ophion series is renowned among small form factor (SFF) PC enthusiasts for its sleek design, robust build quality, and impressive hardware compatibility. While many are familiar with the tempered glass versions, the aluminum side panel variants offer a unique blend of aesthetics, durability, and thermal performance. This comprehensive guide will walk you through everything you need to know about acquiring, building, and optimizing a Raijintek Ophion with aluminum side panels, complete with detailed explanations, step-by-step instructions, and a rich assortment of images and videos to enhance your understanding.
The Raijintek Ophion series stands out in the SFF market for several reasons:
- Premium Materials: High-quality aluminum and steel construction.
- Compact Size: Mini-ITX and Micro-ATX compatibility in a small footprint.
- Hardware Support: Accommodates full-length GPUs, SFX/ATX power supplies, and advanced cooling solutions.
- Modern Aesthetics: Minimalist design with options for both glass and aluminum side panels.
Choosing aluminum side panels for your Ophion case offers several distinct benefits:
- Improved Durability: Aluminum panels are less prone to shattering compared to tempered glass.
- Enhanced Cooling: Vented or perforated aluminum panels allow for better airflow, aiding in GPU and CPU cooling.
- Reduced Weight: Aluminum is lighter than glass, making the case easier to transport.
- Sleek Appearance: Brushed or anodized finishes provide a modern, understated look.
The Raijintek Ophion family includes several models, with both tempered glass and aluminum side panel options. For aluminum panels, look for:
- Ophion ALS: Full aluminum side panels.
- Ophion M EVO ALS: Micro-ATX support with aluminum panels.
- Ophion 7L: Mini-ITX with aluminum front and side panels.
- Official Raijintek Website: Browse the latest models and check for ALS (Aluminum Side) variants.
- Authorized Retailers: Online stores like Amazon, Newegg, and specialist PC hardware shops often carry both glass and aluminum versions.
- Aftermarket Panels: Some third-party manufacturers and community modders offer replacement aluminum panels for existing Ophion cases.
> Tip: Always verify the product description and images to ensure you are purchasing the aluminum side panel version.
If you already own an Ophion with glass panels, you can often purchase replacement aluminum panels separately. These are typically available through:
- Raijintek's official parts store
- Community forums and marketplaces
- Custom modding shops
- Panel Fitment: Ensure the replacement panels are designed for your specific Ophion model (EVO, M EVO, 7L, etc.).
- Ventilation: Opt for vented panels if you prioritize cooling.
- Color and Finish: Match the panel finish (black, silver, brushed, anodized) to your case.
- Carefully unbox your Raijintek Ophion with aluminum side panels.
- Inspect the panels for any damage or manufacturing defects.
- Gather all included accessories: screws, cable ties, dust filters, and instruction manual.
- Each panel is secured with two screws at the top and two at the bottom.
- Use a Phillips screwdriver to remove the screws and gently slide off the panels.
- Motherboard: Install a Mini-ITX or Micro-ATX motherboard, depending on your case model.
- Power Supply: SFX or ATX PSU compatibility (check your specific model).
- GPU: Supports full-length graphics cards (up to 410mm in some models).
- Storage: Multiple 2.5” and 3.5” drive mounts available.
- Motherboard: Secure with standoffs and screws.
- CPU and Cooler: Install before placing the motherboard in the case for easier access.
- Memory and Storage: Slot in RAM and attach SSD/HDD.
- Power Supply: Mount in the designated area, route cables for optimal management.
- Graphics Card: Use the included PCIe riser cable for vertical mounting.
- Use the provided cable ties and routing channels.
- Modular PSUs and M.2 storage help minimize clutter.
- Plan cable paths before finalizing component placement.
- Once all components are installed and cables managed, align the aluminum panels and secure with screws.
- Ensure all ventilation holes are unobstructed.
- Vented Panels: Aluminum panels with perforations enhance airflow, especially for high-power GPUs.
- Fan Placement: Top and bottom fan mounts support additional cooling.
- Dust Filters: Magnetic filters on the top and bottom help keep your system clean.
- The combination of vented aluminum panels and strategic fan placement ensures excellent cooling, even in compact builds.
- Expect slightly higher noise levels compared to fully enclosed cases due to the open design, but temperatures remain well-controlled.
- Use as few cables as possible; opt for modular PSUs.
- Route cables along the edges and behind the motherboard tray.
- Secure loose cables with the included zip ties.
- The Ophion with aluminum side panels consistently delivers excellent thermal results, thanks to its open, vented design.
- Even under heavy load, CPU and GPU temperatures remain within safe limits.
- The semi-open design means noise levels are a bit higher than in fully enclosed cases.
- Fan selection and speed curves can help balance noise and cooling.
performance of the Raijintek Ophion Evo, including a step-by-step assembly and thermal benchmarks.
Check the model number and product description. ALS (Aluminum Side) versions or mentions of "aluminum side panels" in the specs confirm compatibility.
Yes, Raijintek offers black, silver, and sometimes white finishes. Always verify availability with the retailer.
Minimal impact, but if you rely heavily on Wi-Fi or Bluetooth, consider using external antennas for optimal performance.
Yes, with proper tools and measurements, custom panels can be fabricated, but ensure adequate ventilation and precise fitment.
Most Ophion models support GPUs up to 330mm–410mm, depending on the specific case variant.
The Raijintek Ophion with aluminum side panels is a superb choice for enthusiasts seeking a compact, stylish, and high-performance PC case. With its robust aluminum construction, excellent cooling potential, and flexible hardware support, it stands out as one of the best SFF options on the market. Whether you're building from scratch or upgrading your current system, following this guide will ensure you get the most out of your Ophion experience.
By choosing aluminum side panels, you benefit from improved durability, enhanced ventilation, and a modern aesthetic that complements any setup. With careful planning, proper component selection, and attention to detail, your Raijintek Ophion build will not only look great but perform exceptionally well.
- Aluminum panels are lighter, more durable, and typically better for airflow if vented. Glass panels offer a clear view of your components but are heavier and more fragile.
- Yes, many Ophion models allow you to purchase replacement aluminum panels. Ensure compatibility with your specific model before buying.
- Vented aluminum panels significantly improve airflow, which helps keep GPU and CPU temperatures lower, especially during gaming or heavy workloads.
- Official Raijintek website, authorized retailers like Amazon and Newegg, or through community modding forums and aftermarket suppliers.
- The build process is nearly identical, but aluminum panels are easier to handle and less prone to damage during installation.
